| Electrical | |
|---|---|
| average input power max (W) | 160 |
| frequency range (MHz) | 406 to 440 |
| impedance (Ω) | 50 |
| output connectors | N-Female |
| selectivity typ at 1 0 mhz | 34 |
| selectivity typ at 1 5 mhz | 44 |
| thru line average power max | 1000 |
| Mechanical | |
|---|---|
| actual shipping weight (lbs) | 25 |
| depth (in) | 14 |
| finish | chromate conversion |
| length height (in) | 4.19 |
| mounting information | 19" Rack Mount |
| net weight (lbs) | 13 |
| shipping dimensions (in) | 6x19x22 |
| width (in) | 19 |
| Environmental | |
|---|---|
| temperature range (°C) | -40 to 60 |
C3034-1-3.1-Spec-Sheet.pdf
