| Electrical | |
|---|---|
| average input power max (W) | 185-300 |
| frequency range (MHz) | 406 to 415 |
| impedance (Ω) | 50 |
| insertion loss (min) (dB) | 1.7 |
| output connectors | N-Female |
| selectivity typ at 1 0 mhz | 27/48 |
| selectivity typ at 1 5 mhz | 37/59 |
| thru line average power max | 300 |
| Mechanical | |
|---|---|
| actual shipping weight (lbs) | 45 |
| depth (in) | 8 |
| finish | chromate conversion |
| length height (in) | 16 |
| mounting information | Tak-Rak (Wall) mountable |
| net weight (lbs) | 32 |
| shipping dimensions (in) | 32x9x42 |
| Width (in) | 32 |
| Environmental | |
|---|---|
| temperature range (°C) | -40 to 60 |
C3037W-1-Spec-Sheet.pdf
