Combiner, 10" cavities, 7CH, 0.06 MHz Sep, 148-174 MHz
Combiner, 10" cavities, 7CH, 0.06 MHz Sep, 148-174 MHz

CT7150F-3

Combiner, 10" cavities, 7CH, 0.06 MHz Sep, 148-174 MHz

$0.00
/
Nur 0 Artikel auf Lager!
• 7 channel combiner with dual stage isolators and 10" high Q bandpass cavity for each channel
• Can be tuned over the 148-174 MHz frequency band Cavities are mounted in Sinclairs Open Frame Rack Two racks included
Electrical
frequency range (MHz) 148 to 174
impedance (Ω) 50
input connectors N-Female
isolation antenna to tx 60
isolation antenna to tx (dB) 60
isolation tx to tx 70
isolation tx to tx (dB) 70
number of channels 7
output connectors N-Female
output vswr 1.5 : 1
Mechanical
depth (in) 21
finish chemical conversion
length height (in) 76
shipping dimensions (in) 21x21x42
width (in) 21
Environmental
temperature range (°C) -30 to 60
