| Electrical | |
|---|---|
| frequency range (MHz) | 480 to 512 |
| impedance (Ω) | 50 |
| input connectors | BNC-Female |
| insertion loss (typ) (dB) | 2 |
| insertion loss typ (dB) | 2 |
| output connectors | BNC-Female |
| Mechanical | |
|---|---|
| actual shipping weight (lbs) | 2 |
| depth (in) | 7.5 |
| finish | chemical conversion |
| length height (in) | 1.3 |
| shipping dimensions (in) | 13x9x3 |
| Width (in) | 4.2 |
| Environmental | |
|---|---|
| temperature range (°C) | -30 to 60 |
FP30401B-3-3-Spec-Sheet.pdf
