Preselector, 3 MHz bandwidth, compact, BNC, 380-400 MHz
Preselector, 3 MHz bandwidth, compact, BNC, 380-400 MHz
Preselector, 3 MHz bandwidth, compact, BNC, 380-400 MHz
Preselector, 3 MHz bandwidth, compact, BNC, 380-400 MHz

FP30401B-5-3

Preselector, 3 MHz bandwidth, compact, BNC, 380-400 MHz

$0.00
/
Only 0 items in stock!
• Suitable for most standard multicoupling requirements
• Can be mounted directly on 1.75 " high receiver multicoupler tray
• Rugged compact construction with BNC type female connectors
Electrical
frequency range (MHz) 380 to 400
impedance (Ω) 50
input connectors BNC-Female
insertion loss (typ) (dB) 2
insertion loss typ (dB) 2
output connectors BNC-Female
Mechanical
actual shipping weight (lbs) 2
depth (in) 7.5
finish chemical conversion
length height (in) 1.3
shipping dimensions (in) 13x9x3
Width (in) 4.2
Environmental
temperature range (°C) -30 to 60
