| Electrical | |
|---|---|
| average input power max (W) | 120 |
| connectors | N-Female |
| frequency range (MHz) | 160 to 174 |
| impedance (Ω) | 50 |
| insertion loss max rx to ant | 0.8 |
| insertion loss max tx to ant | 0.8 |
| isolation (min) (dB) | 75 |
| Mechanical | |
|---|---|
| actual shipping weight (lbs) | 25 |
| depth (in) | 17 |
| finish | chromate conversion |
| length height (in) | 4.17 |
| mounting configurations | 19 inch rack |
| shipping dimensions (in) | 19x8x22 |
| width (in) | 19 |
| Environmental | |
|---|---|
| temperature range (°C) | -30 to 60 |
Q2222E-2-Spec-Sheet.pdf
