| Electrical | |
|---|---|
| average input power max (W) | 125 |
| bandwidth (MHz) | 5 |
| connectors | N-Female |
| field tunable | Yes |
| frequency range (MHz) | 138 to 174 |
| insertion loss typ tx to ant | 0.7 |
| isolation (min) (dB) | 50 |
| isolation (typ) (dB) | 75 |
| vswr max | 1.25 : 1 |
| Mechanical | |
|---|---|
| actual shipping weight (lbs) | 3 |
| depth (in) | 1.4 |
| length height (in) | 2.5 |
| shipping dimensions (in) | 13x9x3 |
| width (in) | 4.5 |
| Environmental | |
|---|---|
| temperature range (°C) | -30 to 60 |
I221(Y)T-(Z)-Spec-Sheet.pdf
