| Electrical | |
|---|---|
| average input power max (W) | 150 |
| bandwidth (MHz) | 132 |
| connector | N-Male or N-Female |
| frequency range (MHz) | 380 to 512 |
| front to back ratio typ | 16 |
| gain nominal (dBd) | 7.5 |
| horizontal beamwidth typ | 80 |
| impedance (Ω) | 50 |
| lightning protection | DC ground |
| pattern | Directional |
| polarization | vertical or horizontal |
| vswr typ | 1.5 : 1 |
| Mechanical | |
|---|---|
| actual shipping weight (lbs) | 7 |
| base pipe diameter | 0.84 |
| depth (in) | 3.82 |
| finish | anodize (black) |
| length height (in) | 34.7 |
| mounting hardware included | Clamp115 |
| radiating element material | aluminum |
| shipping dimensions (in) | 42x9x4 |
| width (in) | 15.1 |
| Environmental | |
|---|---|
| bending moment 100 mph no ice | 15.8 |
| lateral thrust 100 mph no ice | 14.3 |
| rated wind velocity no ice | 185 |
| temperature range (°C) | -40 to 60 |
| tip deflection 100 mph no ice | 0.6 |
SY350-SWBS(XX)(ABK)-Spec-Sheet.pdf
